2D As-Built Survey:
Accurate. Reliable. Built for What’s Next.
When accuracy matters most, Field Services Unlimited delivers. Our 2D As-Built Surveys provide a clear, precise picture of your building’s existing conditions—captured exactly “as-is.” These field-verified drawings are essential for renovations, retrofits, permitting, construction documents (CD), and buildouts.
Whether you're an architect, contractor, store planner, or project manager, you’ll have confidence that the plans you’re working from reflect reality—down to the millimeter.
What’s Included
Our As-Built surveys can be fully customized based on your project needs and may include:
Accurate Floor Plans
Field-verified dimensions for every room, wall, and space.
Exterior Elevations
Detailed drawings of building exteriors.
Mechanical, Electrical, and Plumbing (MEP)
As-built locations of key systems and infrastructure.
Reflected and Structural Ceiling Plans
Layouts of ceiling elements, including lighting and framing.
Roof and HVAC Plans
Documentation for rooftop equipment, drainage, and access.
Benefits for You
Highly Accurate, Reliable Data
Every drawing is created from direct field measurements supported by in-house QA/QC, ensuring that all dimensions “close” properly and the plan has what we call Good Bones—a solid foundation for every phase of your project. We deliver high quality measurements within 2 millimeters.
Customized to Your Scope
We tailor the survey to collect only the data you need, making the process efficient and budget-conscious without sacrificing accuracy. We meet your custom scope needs within 10 days or less.
Reduced Risk of Costly Change Orders
With verified dimensions and system layouts, design professionals can avoid guesswork and costly revisions.
Streamlined Permitting & CD Preparation
As-built plans help expedite design approvals and construction document development, reducing delays and surprises during buildout.
Confidence to Move Forward
Our proven methodology ensures every layer of your project—from architectural to mechanical—is based on valid, trustworthy data.
Bringing our Survey Experts to You. Whenever, Wherever.
Let’s start a conversation about your project today.
